Areva MiCOM C232 - Page 152

8 Information and Control Functions
(continued)
8-2
C232-302-401/402/403/404-603 / C232/EN M/A23
MAIN: Curr. IP,max prim.
005 050
Fig. 3-30
Display of the maximum phase current as a primary quantity.
MAIN: IP,max prim.,delay
005 036
Fig. 3-30
Display of the delayed maximum phase current as a primary quantity.
MAIN: IP,max prim.,stored
005 034
Fig. 3-30
Display of the delayed stored maximum phase current as a primary quantity.
MAIN: Curr. IP,min prim.
005 055
Fig. 3-30
Display of the minimum phase current as a primary quantity.
MAIN: Current A prim.
005 040
Fig. 3-30
Display of phase current A as a primary quantity.
MAIN: Current B prim.
006 040
Fig. 3-30
Display of phase current B as a primary quantity.
MAIN: Current C prim.
007 040
Fig. 3-30
Display of phase current C as a primary quantity.
MAIN: Current Σ(IP) prim.
005 010
Fig. 3-30
Display of the calculated resultant current as a primary quantity.
MAIN: Volt. VPG,max prim.
008 042
Fig. 3-33
Display of the maximum phase-to-ground voltage as a primary quantity.
MAIN: Volt. VPG,min prim.
009 042
Fig. 3-33
Display of the minimum phase-to-ground voltage as a primary quantity.
MAIN: Voltage A-G prim.
005 042
Fig. 3-33
Display of the updated value for phase-to-ground voltage A-G as a primary
quantity.
MAIN: Voltage B-G prim.
006 042
Fig. 3-33
Display of the updated value for phase-to-ground voltage B-G as a primary
quantity.
MAIN: Voltage C-G prim.
007 042
Fig. 3-33
Display of the updated value for phase-to-ground voltage C-G as a primary
quantity.
MAIN: Volt. Σ(VPG)/3 prim.
005 012
Fig. 3-33
Display of the calculated neutral-displacement voltage as a primary quantity.
MAIN: Volt. VPP,max prim.
008 044
Fig. 3-33
Display of the maximum phase-to-phase voltage as a primary quantity.
MAIN: Voltage VPP,min prim
009 044
Fig. 3-33
Display of the minimum phase-to-phase voltage as a primary quantity.
MAIN: Voltage A-B prim.
005 044
Fig. 3-33
Display of the updated value for phase-to-phase voltage A-B as a primary
quantity.
MAIN: Voltage B-C prim.
006 044
Fig. 3-33
Display of the updated value for the phase-to-phase voltage B-C as a
primary quantity.
MAIN: Voltage C-A prim.
007 044
Fig. 3-33
Display of the updated value for the phase-to-phase voltage C-A as a
primary quantity.
