7 Settings
(continued)
7-6
C232-302-401/402/403/404-603 / C232/EN M/A23
PC link
PC: Name of manufacturer
003 183
Fig. 3-6
Setting for the name of the manufacturer.
Note:
This setting can be changed to ensure compatibility.
PC: Bay address
003 068
Fig. 3-6
PC: Device address
003 069
Bay and device addresses are used to address the device in
communication via the PC interface. An identical setting must be selected
for both addresses.
PC: Baud rate
003 081
Fig. 3-6
Baud rate of the PC interface.
PC: Parity bit
003 181
Fig. 3-6
Set the same parity that is set at the interface of the PC connected to the
C232.
PC: Spontan. sig. enable
003 187
Fig. 3-6
Enable for the transmission of spontaneous signals via the PC interface.
PC: Select. spontan.sig.
003 189
Fig. 3-6
Selection of signals transmitted via the communication interface, e.g. from
private range of IEC 60870-5-103.
PC: Transm.enab.cycl.dat
003 084
Fig. 3-6
Enable for the cyclic transmission of measured values via the PC interface.
PC: Cycl. data ILS tel.
003 185
Fig. 3-6
Selection of the measured values that are transmitted in a user-defined
telegram via the PC interface.
PC: Delta V
003 055
Fig. 3-6
A measured voltage value is transmitted via the PC interface if it differs by
the set delta quantity from the last measured value transmitted.
PC: Delta I
003 056
Fig. 3-6
A measured current value is transmitted via the PC interface if it differs by
the set delta quantity from the last measured value transmitted.
PC: Delta P
003 059
Fig. 3-6
The active power value is transmitted via the PC interface if it differs by the
set delta quantity from the last measured value transmitted.
PC: Delta f
003 057
Fig. 3-6
The measured frequency value is transmitted via the PC interface if it differs
by the set delta from the last measured value transmitted.
PC: Delta meas.v.ILS tel
003 155
Fig. 3-6
The telegram is transmitted if a measured value differs by the set delta
quantity from the last measured value transmitted.
PC: Delta t
003 058
Fig. 3-6
All measured data are transmitted again through the PC interface after this
time period has elapsed – provided that transmission has not been triggered
by the other delta conditions.
PC: Time-out
003 188
Fig. 3-6
Setting for the time between the last transmission via the PC interface and
the activation of the second communication channel.
