7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-7
“Logical“ communication
interface 1
COMM1: Function group COMM1
056 026
Canceling function group COMM1 or including it in the configuration. If the
function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
COMM1: General enable USER
003 170
Fig. 3-7
Disabling or enabling the communication interface.
COMM1: Basic IEC870-5enable
003 215
Fig. 3-7
Common settings for enabling all protocols based on IEC 870-5-xxx.
COMM1: Addit. -101 enable
003 216
Fig. 3-7
Enabling additional settings that are relevant for the protocol based on
IEC 870-5-101.
COMM1: Addit. ILS enable
003 217
Fig. 3-7
Enabling additional settings that are relevant for the ILS protocol.
COMM1: MODBUS enable
003 220
Fig. 3-7
Enabling settings relevant for the MODBUS protocol.
COMM1: DNP3 enable
003 231
Fig. 3-7
Enabling settings relevant for the DNP 3.0 protocol.
COMM1: Communicat. protocol
003 167
Fig. 3-7
The setting defines the standard used as basis for the communication
interface protocol.
COMM1: -103 prot. variant
003 178
Fig. 3-8
The user may select either the AREVA D or the AREVA variant of the 103
protocol.
Note:
This setting is hidden unless the IEC 870-5-xxx protocol is enabled.
COMM1: MODBUS prot. variant
003 214
Fig. 3-11
The user may select either the AREVA D or the AREVA variant of the
MODBUS protocol.
Note:
This setting is hidden unless the MODBUS protocol is enabled.
COMM1: Line idle state
003 165
Fig. 3-8, 3-9,
3-10, 3-11,
3-12
Setting for the line idle state indication.
COMM1: Baud rate
003 071
Fig. 3-8, 3-9,
3-10, 3-11,
3-12
Baud rate of the communication interface.
COMM1: Parity bit
003 171
Fig. 3-8, 3-9,
3-10, 3-11,
3-12
Set the same parity that is set at the interface of the control system
connected to the C232.
COMM1: Dead time monitoring
003 176
Fig. 3-8, 3-9,
3-10, 3-11,
3-12
