8 Information and Control Functions
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 8-19
Reset of the following memories:
All counters
LED indicators
Operating data memory
All event memories
Event counters
Fault data
Measured overload data
Recorded fault values
This control action is password-protected (see section entitled ‘Password-
Protected Control Operations’ in Chapter 6).
MAIN: Reset indicat. USER
021 010
Fig. 3-59
Reset of the following displays:
LED indicators
Fault data
MAIN: Rset.latch.trip USER
021 005
Fig. 3-50
Reset of latched trip commands from the local control panel.
MAIN: Reset c. cl./trip c.
003 007
Fig. 3-52
The counters for counting the trip commands are reset.
MAIN: Reset IP,max,stored
003 033
Fig. 3-30
The display for the stored maximum phase current is reset.
MAIN: Reset meas.v. energy
003 032
Fig. 3-36
The display for active and reactive energy output and input is reset.
MAIN: Man. trip cmd. USER
003 040
Fig. 3-51
A trip command is issued from the local control panel for 100 ms. This
setting is password-protected (see section entitled ‘Password-Protected
Control Operations’ in Chapter 6).
Note:
The command is only executed if the manual trip command has been
configured as trip command 1 or 2.
MAIN: Man. close cmd. USER
018 033
Fig. 3-45
A close command is issued from the local control panel for the set reclose
command time. This setting is password-protected (see section entitled
‘Password-Protected Control Operations’ in Chapter 6).
MAIN: Warm restart
003 039
A warm restart is carried out. The device functions as it does when the
power supply is turned on.
MAIN: Cold restart
000 085
A cold restart is executed. This setting is password-protected (see section
entitled ‘Password-Protected Control Operations’ in Chapter 6). A cold
restart means that all settings and recordings are cleared. The values with
which the device operates after a cold restart are the underlined default
settings given in the ‘Range of Values’ column in the Address List. They
are selected so as to block the device after a cold restart.
