7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-31
MAIN: Min.dur. trip cmd. 1
021 003
Fig. 3-50
Setting for the minimum duration of trip command 1.
MAIN: Min.dur. trip cmd. 2
021 004
Fig. 3-50
Setting for the minimum duration of trip command 2.
MAIN: Latching trip cmd. 1
021 023
Fig. 3-50
Specification as to whether trip command 1 should latch.
MAIN: Latching trip cmd. 2
021 024
Fig. 3-50
Specification as to whether trip command 2 should latch.
MAIN: Fct. asg. close cmd.
021 019
Assignment of the signal for the close command.
MAIN: Close cmd.pulse time
015 067
Fig. 3-45,
3-47
Setting for the duration of the close command.
MAIN: Inp.asg. ctrl.enabl.
221 057
Fig. 3-53
Definition of the binary signal used to issue a general command output
enable.
MAIN: Debounce time gr. 1
221 200
Fig. 3-25
MAIN: Debounce time gr. 2
221 203
MAIN: Debounce time gr. 3
221 206
MAIN: Debounce time gr. 4
221 209
MAIN: Debounce time gr. 5
221 212
MAIN: Debounce time gr. 6
221 215
MAIN: Debounce time gr. 7
221 218
MAIN: Debounce time gr. 8
221 221
Setting for the debouncing time.
MAIN: Chatt.mon. time gr.1
221 201
Fig. 3-25
MAIN: Chatt.mon. time gr.2
221 204
MAIN: Chatt.mon. time gr.3
221 207
MAIN: Chatt.mon. time gr.4
221 210
MAIN: Chatt.mon. time gr.5
221 213
MAIN: Chatt.mon. time gr.6
221 216
MAIN: Chatt.mon. time gr.7
221 219
MAIN: Chatt.mon. time gr.8
221 222
Setting for the chatter monitoring time.
MAIN: Change of state gr.1
221 202
Fig. 3-50
MAIN: Change of state gr.2
221 205
MAIN: Change of state gr.3
221 208
MAIN: Change of state gr.4
221 211
MAIN: Change of state gr.5
221 214
MAIN: Change of state gr.6
221 217
MAIN: Change of state gr.7
221 220
MAIN: Change of state gr.8
221 223
Setting for the number of signal changes allowed during the chatter
monitoring time before chatter suppression operates.
MAIN: Cmd. dur.long cmd.
221 230
Fig. 3-110,
3-114
Setting for the command duration of a long command.
