7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-47
DTOC: tI>> PSx
017 006 073 020 074 020 075 020
Fig. 3-73
Setting for the operate delay of the second overcurrent stage.
DTOC: tI>>> PSx
017 007 073 021 074 021 075 021
Fig. 3-73
Setting for the operate delay of the third overcurrent stage.
DTOC: IN> PSx
017 003 073 015 074 015 075 015
Fig. 3-76
Setting for the operate value of the first overcurrent stage (residual current
stage).
Caution!
The range of setting values includes operate values that are not permitted
as continuous current values (see ‘Technical Data’).
DTOC: IN> dynamic PSx
017 081 073 035 074 035 075 035
Fig. 3-76
Setting for the operate value of the first overcurrent stage in dynamic mode
(residual current stage). This operate value is effective only while the timer
stage MAIN: Hold-time dyn. param. is elapsing.
Caution!
The range of setting values includes operate values that are not permitted
as continuous current values (see ‘Technical Data’).
DTOC: IN>> PSx
017 009 073 016 074 016 075 016
Fig. 3-76
Setting for the operate value of the second overcurrent stage (residual
current stage).
Caution!
The range of setting values includes operate values that are not permitted
as continuous current values (see ‘Technical Data’).
DTOC: IN>> dynamic PSx
017 086 073 036 074 036 075 036
Fig. 3-76
Setting for the operate value of the second overcurrent stage in dynamic
mode (residual current stage). This operate value is effective only while the
timer stage MAIN: Hold-time dyn. param. is elapsing.
Caution!
The range of setting values includes operate values that are not permitted
as continuous current values (see ‘Technical Data’).
DTOC: IN>>> PSx
017 018 073 017 074 017 075 017
Fig. 3-76
Setting for the operate value of the third overcurrent stage (residual current
stage).
Caution!
The range of setting values includes operate values that are not permitted
as continuous current values (see ‘Technical Data’).
DTOC: IN>>> dynamic PSx
017 087 073 037 074 037 075 037
Fig. 3-76
Setting for the operate value of the third overcurrent stage in dynamic mode
(residual current stage). This operate value is effective only while the timer
stage MAIN: Hold-time dyn. param. is elapsing.
Caution!
The range of setting values includes operate values that are not permitted
as continuous current values (see ‘Technical Data’).
DTOC: tIN> PSx
017 008 073 027 074 027 075 027
Fig. 3-76
Setting for the operate delay of the first overcurrent stage (residual current
stage).
