7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-49
IDMT: Factor kt,neg PSx
072 054 073 054 074 054 075 054
Fig. 3-88
Setting for factor kt,neg of the starting characteristic (negative-sequence
current system).
IDMT: Min.trip time negPSx
072 078 073 078 074 078 075 078
Fig. 3-88
Setting for the minimum trip time (negative-sequence current system). As a
rule, this value should be set as for the first DTOC stage (I>).
IDMT: Hold time neg PSx
072 072 073 072 074 072 075 072
Fig. 3-88
Setting for the holding time for intermittent short circuits (negative-sequence
current system).
IDMT: Release neg. PSx
072 060 073 060 074 060 075 060
Fig. 3-88
Setting for the release characteristic (negative-sequence current system).
IDMT: Iref,N PSx
072 052 073 052 074 052 075 052
Fig. 3-90
Setting for the reference current (residual current system).
IDMT: Iref,N dynamic PSx
072 005 073 005 074 005 075 005
Fig. 3-90
Setting for the reference current in dynamic mode (residual current system).
This operate value is effective only while the timer stage MAIN: Hold-
time dyn. param. is elapsing.
IDMT: Characteristic N PSx
072 058 073 058 074 058 075 058
Fig. 3-90
Setting for the tripping characteristic (residual current system).
IDMT: Factor kt,N PSx
072 055 073 055 074 055 075 055
Fig. 3-90
Setting for the tripping characteristic (residual current system).
IDMT: Min. trip time N PSx
072 079 073 079 074 079 075 079
Fig. 3-90
Setting for the minimum trip time (residual current system). As a rule, this
value should be set as for the first DTOC stage (IN>).
IDMT: Hold time N PSx
072 073 073 073 074 073 075 073
Fig. 3-90
Setting for the holding time for intermittent short circuits (residual current
system).
IDMT: Release N PSx
072 061 073 061 074 061 075 061
Fig. 3-90
Setting for the release characteristic (residual current system).
