8 Information and Control Functions
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 8-9
Parameter subset selection
PSS: Control via user EXT
036 101
Fig. 3-62
PSS: Activate PS 1 EXT
065 002
Fig. 3-62
PSS: Activate PS 2 EXT
065 003
Fig. 3-62
PSS: Activate PS 3 EXT
065 004
Fig. 3-62
PSS: Activate PS 4 EXT
065 005
Fig. 3-62
PSS: Control via user
036 102
Fig. 3-62
PSS: Ext.sel.param.subset
003 061
Fig. 3-62
PSS: PS 1 activated ext.
036 094
Fig. 3-62
PSS: PS 2 activated ext.
036 095
Fig. 3-62
PSS: PS 3 activated ext.
036 096
Fig. 3-62
PSS: PS 4 activated ext.
036 097
Fig. 3-62
PSS: Actual param. subset
003 062
Fig. 3-62
PSS: PS 1 active
036 090
Fig. 3-62
PSS: PS 2 active
036 091
Fig. 3-62
PSS: PS 3 active
036 092
Fig. 3-62
PSS: PS 4 active
036 093
Fig. 3-62
Self-monitoring
SFMON: Warning (LED)
036 070
Fig. 3-63
SFMON: Warning (relay)
036 100
Fig. 3-63
SFMON: Warm restart exec.
041 202
SFMON: Cold restart exec.
041 201
SFMON: Cold restart
093 024
SFMON: Cold rest./SW update
093 025
SFMON: Blocking/ HW failure
090 019
SFMON: Relay Kxx faulty
041 200
SFMON: Hardware clock fail.
093 040
SFMON: Invalid SW d.loaded
096 121
SFMON: Invalid type of bay
096 122
SFMON: +15V supply faulty
093 081
SFMON: +24V supply faulty
093 082
SFMON: -15V supply faulty
093 080
SFMON: Wrong module slot 1
096 100
SFMON: Wrong module slot 2
096 101
SFMON: Wrong module slot 3
096 102
SFMON: Defect.module slot 1
097 000
SFMON: Defect.module slot 2
097 001
SFMON: Defect.module slot 3
097 002
SFMON: Error K 201
097 038
SFMON: Error K 202
097 039
SFMON: Error K 203
097 040
SFMON: Error K 204
097 041
SFMON: Error K 205
097 042
SFMON: Error K 206
097 043
SFMON: Error K 207
097 044
SFMON: Error K 208
097 045
SFMON: Error K 209
097 200
SFMON: Error K 210
097 201
SFMON: Error K 211
097 202
SFMON: Error K 212
097 203
SFMON: Error K 213
097 204
SFMON: Error K 214
097 205
SFMON: Undef. operat. code
093 010
