8 Information and Control Functions
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 8-15
DEV08: Switch. device open
211 136
DEV09: Switch. device open
211 186
DEV10: Switch. device open
211 236
DEV01: Switch.device closed
210 037
Fig. 3-111
DEV02: Switch.device closed
210 087
DEV03: Switch.device closed
210 137
DEV04: Switch.device closed
210 187
DEV05: Switch.device closed
210 237
DEV06: Switch.device closed
211 037
DEV07: Switch.device closed
211 087
DEV08: Switch.device closed
211 137
DEV09: Switch.device closed
211 187
DEV10: Switch.device closed
211 237
DEV01: Sw. dev. interm.pos.
210 038
Fig. 3-111
DEV02: Sw. dev. interm.pos.
210 088
DEV03: Sw. dev. interm.pos
210 138
DEV04: Sw. dev. interm.pos.
210 188
DEV05: Sw. dev. interm.pos.
210 238
DEV06: Sw. dev. interm.pos.
211 038
DEV07: Sw. dev. interm.pos.
211 088
DEV08: Sw. dev. interm.pos.
211 138
DEV09: Sw. dev. interm.pos.
211 188
DEV10: Sw. dev. interm.pos.
211 238
DEV01: Open command
210 028
Fig. 3-110,
3-111
DEV02: Open command
210 078
DEV03: Open command
210 128
DEV04: Open command
210 178
DEV05: Open command
210 228
DEV06: Open command
211 028
DEV07: Open command
211 078
DEV08: Open command
211 128
DEV09: Open command
211 178
DEV10: Open command
211 228
DEV01: Close command
210 029
Fig. 3-110,
3-111
DEV02: Close command
210 079
DEV03: Close command
210 129
DEV04: Close command
210 179
DEV05: Close command
210 229
DEV06: Close command
211 029
DEV07: Close command
211 079
DEV08: Close command
211 129
DEV09: Close command
211 179
DEV10: Close command
211 229
Interlocking logic
ILOCK: Output 1
250 032
Fig. 3-113
ILOCK: Output 2
250 033
ILOCK: Output 3
250 034
ILOCK: Output 4
250 035
ILOCK: Output 5
250 036
ILOCK: Output 6
250 037
ILOCK: Output 7
250 038
