10 Troubleshooting
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 10-3
SFMON: +24V supply faulty
093 082
The +24 V internal supply voltage has dropped below a minimum value.
1st device reaction / 2nd device reaction: Warm restart / Device blocking
'Warning' output relay: Yes / Yes
'Blocked/faulty' output relay: Yes / Yes
SFMON: -15V supply faulty
093 080
The -15 V internal supply voltage has dropped below a minimum value.
1st device reaction / 2nd device reaction: Warm restart / Device blocking
'Warning' output relay: Yes / Yes
'Blocked/faulty' output relay: Yes / Yes
SFMON: Wrong module slot 1
096 100
SFMON: Wrong module slot 2
096 101
SFMON: Wrong module slot 3
096 102
Module in wrong slot.
1st device reaction / 2nd device reaction: Warm restart / Device blocking
'Warning' output relay: Yes / Yes
'Blocked/faulty' output relay: Yes / Yes
SFMON: Defect.module slot 1
097 000
SFMON: Defect.module slot 2
097 001
SFMON: Defect.module slot 3
097 002
Defective module in slot x.
1st device reaction / 2nd device reaction: – / –
'Warning' output relay: Updating / Updating
'Blocked/faulty' output relay: Yes / Yes
1)
SFMON: Error K 201
097 038
SFMON: Error K 202
097 039
SFMON: Error K 203
097 040
SFMON: Error K 204
097 041
SFMON: Error K 205
097 042
SFMON: Error K 206
097 043
SFMON: Error K 207
097 044
SFMON: Error K 208
097 045
SFMON: Error K 209
097 200
SFMON: Error K 210
097 201
SFMON: Error K 211
097 202
SFMON: Error K 212
097 203
SFMON: Error K 213
097 204
SFMON: Error K 214
097 205
Output relay K xxx defective.
1st device reaction / 2nd device reaction: – / –
'Warning' output relay: Updating / Updating
'Blocked/faulty' output relay: Yes / Yes
1)
