6 Local Control Panel
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 6-5
Keys
‘Up’ and ‘Down’ Keys /
Panel Level:
The effect of using the ‘up’ and ‘down’ keys differs between the individual Panels.
Bay Panel:
The ‘up’ and ‘down’ keys switch between the measured values
selected for this Panel.
Measured Value Panel
: The ‘up’ and ‘down’ keys switch between the pages of
the Measured Value Panel.
Signal Panel:
The ‘up’ and ‘down’ keys switch between events.
Menu Tree Level:
By pressing the ‘up’ and ‘down’ keys, the user can navigate up and down through the
menu tree in a vertical direction. If the unit is in input mode, the ‘up’ and ‘down’ keys
have a different function.
Input mode
:
Parameter values can only be changed in the input mode, which is signaled by the
LED indicator labeled EDIT MODE. By pressing the ‘up’ and ‘down’ keys, the user
can then change the parameter value.
(‘Up’ key: the next higher value is selected.
‘Down’ key: the next lower value is selected.)
With list parameters, the user can change the logic operator of the value element by
pressing the ‘up’ and ‘down’ keys.
‘Left’ and ‘Right’ Keys
/
Panel Level:
Pressing the 'right'/'left' keys switches between Bay Panel and Measured Value
Panel, for example.
Menu Tree Level:
By pressing the ‘left’ and ‘right’ keys, the user can navigate through the menu tree in
a horizontal direction. If the unit is in input mode, the ‘left’ and ‘right’ keys have a
different function.
Input mode
:
Parameter values can only be changed in the input mode, which is signaled by the
LED indicator labeled EDIT MODE. When the ‘left’ and ‘right’ keys are pressed, the
cursor positioned below one of the digits in the change-enabled value moves to the
next digit to the right or left.
(‘Left’ key: the cursor moves to the next digit on the left.
‘Right’ key: the cursor moves to the next digit on the right.)
In the case of a list parameter, the user can navigate through the list of items
available for selection by pressing the ‘left’ and ‘right’ keys.
ENTER Key
Panel Level:
By pressing the ENTER key at the Panel level, the user can go to the first menu tree
level.
Menu Tree Level:
To enter the input mode, press the ENTER key. Press the ENTER key a second time
to accept the changes as entered and leave the input mode. The LED indicator
labeled EDIT MODE signals that the input mode is active.
