3
SECTION 1
GENERAL INFORMATION
AVENGER (V)
Engine: Kohler 674 cc (26 h.p.) V-twin 4 cycle, liquid cooled
Transmission: 2 forward speeds, neutral and reverse
Clutch: Variable speed torque converter
Fuel Capacity: 29 Litre (6.3 Imp. Ga., 7.6 U.S Gal.)
Steering/Brakes: Hydraulic Caliper, 10.25" with holding brake system
Drive Chains: Double RC-50 roller chains & Single RC 60 Roller
chain
Electrical: 12 volt D.C. battery, 435 cranking amps at 0 F;
25 Amp charging system, electronic ignition
Speed: Land - 32 km/hr (20 mph)
Water - 3 km/h (2 mph)
Load Capacity: Land - 6 persons or 522kg (1150lbs)
SEE SECT.1.4.1 Water - 4 adults or 317kg (700lbs)
Tires: 25x11.5-9NHS, 2 ply
Dry Weight: 542kg (1195lbs)
AVENGER EFI (H)
Engine: Kohler 747 cc (31 h.p.) V-twin 4 cycle, liquid cooled
Transmission: 2 forward speeds, neutral and reverse
Clutch: Variable speed torque converter
Fuel Capacity: 29 Litre (6.3 Imp. Ga., 7.6 U.S Gal.)
Steering/Brakes: Hydraulic Caliper, 10.25" with holding brake system
Drive Chains: Double RC-50 roller chains & Single RC 60 Roller
chain
Electrical: 12 volt D.C. battery, 435 cranking amps at 0 F;
25 Amp charging system, electronic ignition
Speed: Land - 32 km/hr (20 mph)
Water - 3 km/h (2 mph)
Load Capacity: Land - 6 persons or 522kg (1150lbs)
SEE SECT.1.4.1 Water - 4 adults or 317kg (700lbs)
Tires: 25x11.5-9NHS, 2 ply
Dry Weight: 542kg (1195lbs)
ARGO FRONTIER (F)
Engine: Briggs & Stratton Vanguard, 627 cc cooler cleaner
running (18 h.p.) V-Twin, 4 cycle, air cooled
Transmission: 2 forward speeds, neutral and reverse
Clutch: Variable speed torque converter
Fuel Capacity: 29 Litre (6.3 Imp. Ga., 7.6 U.S Gal.)
Steering/Brakes: Hydraulic Caliper, 10.25" with holding brake system
Drive Chains: Single RC-60 roller chain
Electrical: 12 volt D.C. battery, 435 cranking amps at 0 F;
20/50 Amp magneto type charging system,
electronic ignition
Speed: Land - 39 km/h (24 mph)
Water - 3 km/h (2 mph)
Load Capacity: Land - 4 persons or 317 kg (700 lbs.)
SEE SECT.1.4.1 Water - 2 adults or 158 kg (350 lbs.)
Tires: 24x10.00-8NHS, 8 ply
Dry Weight: 414 kg (910 lbs.)
1.4.1 Argo Vehicle Capacity
Vehicle capacity includes occupants, cargo, fuel, and
all accessories. Capacity for occupants and cargo is
reduced by the weight of accessories as shown in the
chart below.
Available vehicle capacity must be reduced if your vehicle is
equipped with any accessories. Reduce the available capacity
by the total weight of accessories fitted to your vehicle.
Reduce By
Accessory On On
On Vehicle Land Water
Regular Tracks 6x6 135 lbs. (60 kg) 85 lbs. (40 kg)
Regular Tracks 8x8 175 (80) 110 (50)
Supertracks 6x6 145 (65) 90 (40)
Supertracks 8x8 210 (95) 135 (60)
Avenger Track Kit 240 (110) 150 (68)
Winch Kit 50 (23) 50 (23)
Brush Guard 11 (5) 11 (5)
Windshield 33 (15) 33 (15)
Roll Bar 6x6 50 (23) 50 (23)
ROPS 6x6 130 (60) SEE WARNING
ROPS 8x8 140 (64) 140 (64)
ROPS 8x8 Avenger 155 (70) 155 (70)
Half Top 16 (7) 16 (7)
Full Top 8x8 27 (12) 27 (12)
Full Top 6x6 22 (10) 22 (10)
Snow Plow 190 (85) SEE WARNING
Dump Box 100 (45) 500 (225)
Rear Bench Seat 34 (15) 34 (15)
Do NOT use an Argo on water when equipped with a
snow plow. Do NOT use an Argo 6x6 in water when
equipped with a ROPS. The increased weight of the
snow plow out front or the top-heavy weight of the ROPS
on the 6x6 will make the Argo unstable and could cause
the vehicle to capsize, causing injury or drowning to
the driver and passengers.
1.5 REAR SEATS - 8 WHEEL MODELS
Argo 8 wheel models are fitted with “quick-release” rear seats.
Removal
1. Grasp the inner edge of the rear seat at both ends.
2. Lift the inner edge of the rear seat upwards until both plas-
tic bumpers are clear of the upper body.
3. Using an upward motion, pull the seat toward the centre of
the rear compartment.
4. Remove the seat.
Installation
1. Place the rear seat over the seat mounting holes in the
upper body. Insert the large seat washers through the holes.
2. Using downward pressure, slide the seat towards the out-
side of the vehicle to lock it in place.
