62
The ROPS design provides reasonable protection from injury
in the event of a rollover. DO NOT rely on it to protect the
occupants from irresponsible driving.
The ROPS has been designed to meet the requirements of the
Occupational Health and Safety Act - Regulation 856 ‘Roll-
Over Protection Structures’ for the Province of Ontario, Canada.
Seat belts must be properly adjusted and worn by all
occupants at all times EXCEPT when operating in wa-
ter. 6x6 vehicles equipped with 648-40 ROPS should
not be used in water operation. Never carry more peo-
ple in the vehicle than there are seat belts for.
Articles must not be placed on top of the ROPS.
Use caution when travelling on uneven ground; the
ROPS reduces vehicle stability.
No part of the ROPS shall be drilled, welded or altered
in any way without the manufacturer’s authorization.
Do not exceed maximum gross vehicle weight of 907 kg
(2000 lb.), Avenger 1066 kg (2350 lb.).
Use caution when travelling tree-lined trails. Branches
could be knocked down, causing injury to the vehicle
occupants.
FAILURE TO COMPLY WITH THE ABOVE COULD RE-
SULT IN PERSONAL INJURY OR DEATH.
DO NOT use the ROPS as an attachment point for tow-
ing or winching the Argo.
Check fastener tightness annually. Inspect for and re-
place any damaged or worn parts of the ROPS and the
seat belts.
11.22 REAR BENCH SEAT (Part No. 849-60 & 849-80)
This bench seat assembly is similar to the front bench seat
design, providing a back rest and more comfort for two per-
sons riding in the rear compartment of any current Argo 8 x 8
model. The seat cushion and back rest are easily removed to
use the rear compartment for cargo.
Always ensure that the spring loaded pull pin (Part
No. 849-72) on each side is fully engaged after install-
ing the seat. Pull the seat hard to ensure that it is
secured properly.
Never attach a tow line to the handrail of the seat back
rest.
When a roll over protection structure (ROPS) is in-
stalled, seat belts must be installed for rear bench seat
passengers and used properly.
SECTION 11
ACCESSORY INFORMATION
11.23 DUMP BOX KIT (Part Nos. 835-00 & 835-01)
The dump box kit can be installed on any Argo 8 x 8 (except the
Avengers). It improves the load carrying versatility of the Argo.
Keep hands and arms clear when lowering box.
No riders in box; riders can fall off and be killed
Installation of dump box reduces vehicle capacity;
On land: 408kg (900lbs)
On water: 227kg (500lbs)
(Capacity includes: occupants, cargo and fuel)
Tie loads down. Spread loads evenly.
Operators should use caution when turning in confined
spaces and close to bystanders. The dump box decreases
the rear clearance of the Argo.
Never operate dump while moving.
Operate dump on level ground only.
The dump box decreases the vehicle stability. Operate
the vehicle with extra precautions when on uneven ter-
rain and in water.
Note: Frequent use of the powered dump box will result
in battery drain. The installation of an alternator kit is
strongly suggested.
11.23.1 Dump Box Operating Guidelines
1. For quick removal of the box disconnect the actuator or
springs then disconnect the rear hinge pins 104-32.
2. The rear side seats can still be used if you remove the
dump box and undercarriage.
3. A rear bench seat kit 849-60 can be used when the dump
box is removed. The undercarriage frame support plates
are in the same location as the rear bench seat frame sup
port plates. So the seat can quickly be attached without
any additional mounting.
11.24 ROLL BAR KIT (Part No. 648-15)
The roll bar is designed for use on all Argo 6 x 6 models. The
roll bar provides some roll over protection and lap belts for the
driver and front seat passenger.
When the Roll Bar Kit is installed, ALWAYS wear seat
belts when operating the vehicle on land. REMOVE
seat belts when entering water.
Maximum total vehicle weight must not exceed 1465
lbs. or 665 kg. which means 2 people and 100 lbs. or 46
kg. of cargo in the vehicle.
Never attach anything to the Roll Bar other than On-
tario Drive & Gear 648-15 Roll Bar specific accesso-
ries.
