9
the Operators Manual.) If you must cross ice-covered bodies
of water, take along an able-bodied person to assist if difficul-
ties are encountered.
Land Operation
When operating the vehicle on land, make sure all occupants
including yourself are wearing the seat belts and you are
strapped in your seat firmly at all times. Loss of seating posi-
tion could result in loss of control of the vehicle.
Be constantly aware of the overall height and width of your
Argo vehicle equipped with the ROPS. Watch out for low
objects, eg. brush, branches, etc. which could strike the ROPS
and cause the vehicle to stop abruptly, rollover, or go out of
control.
Due to the weight of the ROPS, your vehicle is more likely to
rollover on land than a standard Argo vehicle. Ensure passen-
gers and operator remain seated at all times and keep all cargo
low and evenly distributed.
Seat belts must be properly adjusted and worn by all occu-
pants at all times EXCEPT when the vehicle is floating in wa-
ter.
We have provided this information because we want you to
enjoy your mobility in the outdoors safely. However, please
keep in mind that all the warnings and instructions in the
world cannot replace common sense. You’ve got it – please
use it.
2.5 FUELING THE VEHICLE
Gasoline is extremely flammable and can ex-
plode under certain conditions. Do not add
fuel while the engine is running or hot. If fuel
is spilled in, on or around the vehicle, wipe it
up immediately. Flush out any fuel spilled in
the vehicle with water and allow it to drain
out through the drain plug holes. Do not
smoke when filling the fuel tank.
Use clean, fresh, unleaded gasoline in all models of the ARGO.
Minimum 87 octane fuel is recommended.
Leaded gasoline can be used as a substitute fuel. However, if
leaded gasoline is used, the engine will require more frequent
servicing.
Never use gasoline containing methanol or white gas since
engine or fuel system damage could occur.
All C, R, B, A, N and S models of the ARGO are equipped with
a 32 litre (7.0 Imp. Gal., 8.4 U.S. Gal.) “see-thru” polyethelene
fuel tank located underneath the drivers seat. All Argo Avenger
and Frontier models are equipped with a 29.0 litre (6.3 Imp.
Gal, 7.6 U.S. Gal.)"see-thru" polyethelene fuel tank located
under the driver's seat. Depending on loading and driving
conditions, an ARGO can be driven for 7 to 12 hours on one
tank of fuel. Verify your vehicle’s actual fuel consumption
before attempting any long trips. Never travel in remote areas
or set out on long trips without a full tank of fuel and adequate
spare fuel stored in approved watertight fuel containers.
The fuel filler neck and fuel cap are located on the right side of
the vehicle behind the drivers seat. Replace the fuel cap if
fuel leakage occurs, or if moisture is detected in the fuel. Use
ARGO Part No. 126-46 fuel cap.
Never fill the tank to the point where the fuel level rises into
the filler neck. If the tank is overfilled, heat may cause the fuel
to expand and overflow through the vent.
Portable fuel containers may contain contaminants (dirt, wa-
ter, etc.) that will cause engine operating problems. Use only
clean, approved gasoline containers.
After filling the fuel tank, be sure the fuel cap is replaced
securely. Do not drive the vehicle unless the fuel cap is prop-
erly in place.
Never use untreated gasoline that has been stored for
more than 45 days. Stale gasoline can cause
deposits to form in the fuel lines and carburetor. These
deposits clog the fuel system and cause engine starting
and operating problems.
When storing the ARGO for 45 days or more, use ARGO
Part No. 127-77 Fuel Stabilizer to treat fuel in the fuel
tank and fuel containers.
2.6 VENTED FUEL SYSTEM - ALL MODELS
All ARGO models have fuel systems that are vented through
a special hose connected to the filler neck assembly that runs
along the upper body to a fitting at the left rear.
SECTION 2
GENERAL OPERATING INFORMATION
