Table 1-1 (1-Way Air Discharge Semi-Concealed)
Table 1-2 (1-Way Air Discharge Semi-Concealed Slim)
Part Name Figure Q’ty Remarks
Flare insulator
2
Insulating tape
3
2
Vinyl clamp
8
Hose band
1
Packing
1
Drain insulator
1
Drain hose
1
Installation gauge
8
For gas and liquid tubes
For gas and liquid tubes
For gas and liquid tube flare nuts
For flare insulator
For securing drain hose
For drain joint
For drain joint
For measuring clearance between the unit and ceiling
Special washer
For suspension bolts
1 For securing drain hose
(Black)
(White)
(White)
Part Name Figure Q’ty Remarks
Full-scale installation diagram
1
Special washer
8
Flare insulator
2
Insulating tape
2
2
Vinyl clamp
8
Hose band
1
Packing
1
Drain insulator
1
Sealing putty
1
Cable
1
For determining suspension bolt pitch
For temporarily suspending indoor unit from ceiling
For gas and liquid tubes
For gas and liquid tubes
For gas and liquid tube flare nuts
For flare insulator
For securing drain hose
For drain joint
For drain joint
For sealing recessed portion of po
wer supply
Drain hose
1
(Black)
For securing drain hose
Connection cable for fan motor
