Chapter 1: Introduction to the Argus TubeSpec
4 NOV CTES Argus TubeSpec User Guide
System Capabilities
• DSP internally processes ~1,000 wall-thickness calculations per second.
• Output of twelve “minimum,” twelve “maximum,” and twelve “average” circumferential wall-thick-
ness measurements (in inches) per second.
• Wall thickness accuracy to ± .005
" for thicknesses of .090" or greater.
• Diameter accuracy of ± .015
" for all tubing sizes.
• Ovality measurements.
• With either a customer-supplied depth measuring tool or the NOV CTES-optionally supplied depth-
measuring encoder, the Argus TubeSpec accurately charts the position of tubing-wall loss.
• Provides 100 percent coverage longitudinally on all tubing at speeds up to 180 ft/min.
• Provides 100 percent coverage circumferentially on tubing sizes 2
" or smaller.
Mechanical Information
Measuring head
Weight 40 lbs.
Length 15.8 in.
Height 15.2 in.
Width 17.2 in.
Control Box
Weight 33 lbs.
Length 18 in.
Width 15 in.
Height 10 in.
Cable Length 50 ft.
Lube Tank Assembly
Dry Weight 55 lbs.
Length 39 in.
Width 22 in.
Height 27 in.
Volume 208 liters
Fluid Group 1
