Chapter 2: Overview of the Argus TubeSpec System
22 NOV CTES Argus TubeSpec User Guide
Oiler Assembly Maintenance and Safety Practices
The oiler assembly is illustrated in the figure entitled Oiler Assembly.
Not easily viewable from the referenced figure is the precise location of the oiler body (in relation to the
top and bottom covers) when mounted on the tubing. The oiler body has a groove in the OD of the plastic
housing that fits into the larger semi-circle cutouts in the top and bottom covers. This groove keeps the
oiler assembly oriented in the correct direction and locks it in place.
Each oiler assembly is sized to accommodate the two sizes of tubing potentially used with a particular
measuring head (within the constraints described in Tubing Sizes for Argus TubeSpec Model Numbers
).
The user adjusts the oiler assembly to conform to one of two possible tubing sizes specific to a measuring
head by switching part numbers 5 and 6 with part numbers 27 and 28.
Part numbers 3, 5, 6, 27, and 28 are all wear parts, so must be inspected after each job for serviceability:
• When the UHMW bearing (part numbers 6 and 28) is .25" over nominal tubing, it must be replaced.
Change the UHMW bearing by following the instructions in Step k. on page 42.
• If the sponge (part number 3) is packed with debris, clean it before the next use.
12 2 66B-7190-0008-22 Elbow, 90 Degree, Female
13 2 66B-7190-0008-21 Nipple, Close Hex
14 2 66B-7190-0008-20 Fitting, Push-lock
15 4 7190-1400-50 Nut, Hex
16 25 66B-7190-0008-34 Tubing, Clear PVC, 15ft, 1-1/2" ID, 1-7/8" OD
17 1 66B-7190-0008-33 Clamp, Worm-drive Hose
18 0 n/a No Part Listed Here
19 22 66B-7190-0008-24 Insert, Hex Press-fit, 18-8 Ss
20 22 66B-7190-0008-26 Screw, Button Head Socket Cap, 18-8 Ss
21 2 66B-7190-0008-25 Screw, Button Head Socket Cap, 18-8 Ss
22 3 66B-7190-0008-29 Coupler, Quick Disconnect
23 3 66B-7190-0008-28 Nipple, Quick Disconnect
24 1 66B-7100-0001-40 Label, Mounting
25 1 66B-7100-0001-41 Label, Arrow
26 2 66B-7190-0008-17 Fitting, 3/8" Hose Barb, to 1/4” male NPT pipe
27 2 See Item #5 Scraper, Polyurethane
28 2 See Item #6 Bearing, UHMW
29 1 7190-1404-86 Tee, Barb 1.5” Tubing
