Chapter 2: Overview of the Argus TubeSpec System
14 NOV CTES Argus TubeSpec User Guide
The TubeSpec Packer Pressure-control System
A packer pressure-control system resides within the TubeSpec system for the purpose of maintaining
proper coupling between the tubing and the UT sensors.
The system allows the user to set and maintain the desired packer pressure as conditions at the measuring
head change. As tubing of varying sizes and shapes is introduced to the system, and as the packers wear,
regulated hydraulic pressure is applied to the pistons to actuate (move) them into position to generate ade-
quate force to sufficiently compress the packers to create coupling.
27 1 66B-7190-0008-70 Swagelok Fitting Straight 1/8"NPT 1/4"
tube
28 3 66B-7190-0008-69 Swagelok Elbow Fitting 90 Degree
29 1 66B-7190-0008-54 ¼" NPT Male to Female Elbow 45 degree
30 1 66B-7190-0008-53 ¼" NPT Hex nipple
31 2 66B-7100-1008-50-C Mounting Post
32 8 66B-7190-0008-73 Side Rail Bolt 1" 3/8-16
33 2 66B-7100-1009-34 Lemo Connector Housing Cover
34 2 66B-7190-0008-52 Lemo Connector Housing Cover O-ring
35 2 66B-7100-1009-76 Lemo Connector Housing W / label
36 2 66B-7190-0009-36 Lemo Connector (Socket)
37 2 66B-7190-0009-34 Recp. Dust Cover
38 2 66B-7190-0001-43 Screw pan head 6-32 X ¼"
39 2 66B-7100-0008-51 Proximity Sensor Ring
40 6 66B-7190-0008-51 Flat point set screws 4-40
41 2 66B-7100-1003-07 Prox Probe Spring
42 2 66B-7190-0008-64 Proximity Sensors
43 2 66B-7100-0008-62 Proximity Probe Bracket Assembly
44 2 66B-7190-0008-50 SHCS 10-24 ¾" long, ss
45 4 66B-7190-0008-49 SHCS ¼-20 1-3/4" long, ss
46 2 66B-7190-0008-48 30mm Locking nut for Proximity Probe
47 2 66B-7190-0008-68 Short Braided Flex Hydraulic Hose 6"
48 1 66B-7190-0008-29 Coupler Quick Disconnect
49 3 66B-7190-0009-49 Fitting 1/8" X 1/8" Pipe Sz, Adapter
50 1 66B-7190-0008-47 1/4" tube to 1/8" NPT Elbow 45 deg
Item Quan-
tity
Part Number Description
