Chapter 2: Overview of the Argus TubeSpec System
Argus TubeSpec User Guide NOV CTES 13
5 2 See “Packer Ele-
ments and CT Guide
Rings” on page 16.
See “Packer Elements and CT Guide
Rings” on page 16.
6 1
66B-7100-1008-92
66B-7100-1009-09
66B-7100-1007-95-C
66B-7100-1009-10
66B-7100-1009-11
End Plate Set - Proximity Sensor Side
Small Body, Thick (1.25"-1.5")
Small Body, Medium (1.5"-1.75")
Small Body, Thin (1.75"-2")
Large Body, Thick (2 3/8"-2 5/8")
Large Body, Thin (2 5/8" - 2 7/8")
7 2
7100-1401-01
7100-1401-02
Sensor Ring
Small Body (1.25" - 2.0")
Large Body (2 3/8" - 2 7/8")
8 66B-7190-0008-66 Roll Pin 1/8" diameter x 1" long
9 4 66B-7100-1007-98-C Clamp Lug
10 4 66B-7100-1007-99 Clamp Lug Nut
11 2 66B-7190-0008-58 Bolt, Shoulder
12 2 66B-7190-0008-59 Nut
13 12 66B-7100-1008-09-D UT Sensor
14 6 66B-7100-1008-00 Piston Manifold Bolts
15 2
7100-1400-74
7100-1400-66
Cable Cover
Small Body (1.25" - 2.0")
Large Body (2 3/8" - 2 7/8")
16 2
7100-1400-75
7100-1400-65
Cable Cover
Small Body (1.25" - 2.0")
Large Body (2 3/8" - 2 7/8")
17 16 66B-7190-0008-77 Wire Cover Bolts ¼" ¼-20
18 2 66B-7190-0008-57 Cable Grommet MS
19 2 66B-7190-0008-61 Proximity Sensor Cable
20 2
66B-7100-1008-06-A
66B-7100-1008-26
Piston Housing
Small Body (1.25" - 2.0")
Large Body (2 3/8" - 2 7/8")
21 4 66B-7190-1003-06 3/16" plug for piston
22 2 66B-7190-0008-76 1/8" NPT Plug
23 6 66B-7190-0008-67 Polypak Seal
24 6 66B-7100-1007-97-A Piston
25 2 66B-7190-1003-09 Bullet-Nose Aligning Dowel
26 2 66B-7100-1010-73
66B-7100-0008-63
Side Rail Assembly Large
Side Rail Assembly Small
Item Quan-
tity
Part Number Description
To Next Page
