Chapter 2: Overview of the Argus TubeSpec System
16 NOV CTES Argus TubeSpec User Guide
Packer Elements and CT Guide Rings
All Packer Elements: 1 set used in each Argus Tube Spec
All CT Guide Rings: 2 sets used in each Argus Tube Spec
The TubeSpec Electronics Control Box
The Argus TubeSpec control box consists of multiple boards that power, acquire data, and interpret signals
from the 12 ultrasonic transducer (UT) sensors and two proximity probes/sensors in the measuring head.
The DSP internally processes each of the [12 UT- and two proximity-probe] readings 80 times per second.
It applies a complex set of algorithms to the data, translates the data to engineering units as wall thickness
and diameter, and passes Min, Max, and Average data (once per second) to a PC via a serial stream (using
a serial port).
On the PC, OrionNET software provides data storage and an interface with which the user may view real-
time data in graphic format.
Body
Size
Energizer (CT Size
Range)
CT Size
Packer Element
Part Number
CT Guide Ring
Part Number
Small Thick (1.25” and 1.5”) 1.25” 66B-7100-1007-85 66B-7100-1008-91
Small Thick (1.25” and 1.5”) 1.5” 66B-7100-1007-88 6B-7100-1008-90
Small Medium (1.5” and 1.75”) 1.5” 6B-7100-1007-86 66B-7100-1009-05
Small Medium (1.5” and 1.75”) 1.75” 66B-7100-1007-89 66B-7100-1009-06
Small Thin (1.75” and 2.0”) 1.75” 66B-7100-1007-87 66B-7100-1008-69
Small Thin (1.75” and 2.0”) 2.0” 66B-7100-1007-90 66B-7100-1008-70
Large Thick (2.375” and 2.625”) 2.375” 66B-7100-1008-74 66B-7100-1008-71
Large Thick (2.375” and 2.625”) 2.625” 66B-7100-1008-75 66B-7100-1008-72
Large Thin (2.625” and 2.875”) 2.625” 66B-7100-1008-76 66B-7100-1009-07
Large Thin (2.625” and 2.875”) 2.875” 66B-7100-1008-77 66B-7100-1008-73
