Chapter 2: Overview of the Argus TubeSpec System
30 NOV CTES Argus TubeSpec User Guide
Lube Tank: Front View
The next photo shows the air regulator, on/off switch, pump air filter, level gauge, pump air regulator, and
pump lubricator.
SAE 10W-30 oil is used in the pump lubricator. The oil should last one to two months depending on the
pump’s usage. Oil may be added to the pump lubricator through the small black screw plug on the top.
Lube Tank: Pump-control-side View
At installation, drill a hole in each mounting tab (shown at bottom of the above and below photos) and use
bolts to secure the tank to a level surface. See Lube Tank Kit Installation
for additional information.
Air Regulator Valve
and
Green On/Off Switch
To Next Page
