Chapter 1: Overview Specifications
Quick Start Guide: 7500N Series Modular Switches 5
7508N Series System Full chassis loaded with
2 DCS-7500E-SUP
6 DCS-7508E-FM
8 DCS-7500E-36Q-LC
5500 W / 6400 W
Full chassis loaded with
2 DCS-7500-SUP2
6 DCS7508R-FM
8 DCS-7500E-36Q-LC
5820 W / 6880 W / 7750 W
Full chassis loaded with
2 DCS-7500-SUP2,
6 DCS7508R-FM
8 DCS-7500R-36CQ-LC
7720 W / 8990 W / 9880 W
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7508R-FM,
8 DCS-7500R-36Q-LC
4600 W / 5360 W / 6230 W
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7508R-FM
8 DCS-7500R-48S2CQ-LC
3270 W / 3900 W / 4740 W
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7508R-FM
8 DCS-7500RM-36CQ-LC
9100 W / 10300 W / 11000 W
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7508R-FM
8 DCS-7500R2-36CQ-LC
6400 W / 7300 W/ 7900 W
7512N Series System
Note: 7512N systems
support only 7500R and
7500R3 Series Line cards.
Full chassis loaded with
2 DCS-7500-SUP2,
6 DCS75012R-FM
12 DCS-7500R-36CQ-LC
12800 W / 14700 W / 15300 W
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7512R-FM
9 DCS-7500R-36CQ-LC
3 DCS-7500R-36Q-LC
11600 W / 13300 W / 13900 W
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7512R-FM
3 DCS-7500R-36CQ-LC
9 DCS-7500R-36Q-LC
9300 W / 10600 W / 11200 W
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7512R-FM
12 DCS-7500RM-36CQ-LC
14400 W / 16600 W / 18000 W*
Full Chassis loaded with
2 DCS-7500-SUP2
6 DCS-7512R-FM
12 DCS-7500R2-36CQ-LC
10200 W / 11800 W / 13200 W
Table 1-2 7500N Series power specifications (Continued)
Module Type Part Number
Power Draw (Typical /
{Hot}Maximum)
