6 Quick Start Guide: 7500N Series Modular Switches
Specifications Chapter 1: Overview
Note1: Includes typical power supply conversion inefficiency. Contact your local Sales Engineer for
7500 power calculator details.
Note2: Power numbers given as Typical/Maximum or Typical/Hot/Maximum where Hot is defined as
40°C Sea Level.
* Not N+N redundant power at worst case Temp/Elevation.
7516N Series System
Note: 7516N systems
support only 7500R Series
Line cards.
Full chassis loaded with
2 DCS-7516-SUP,
6 DCS7516R-FM
16 DCS-7500R-36CQ-LC
16 PWR-3KT-AC-RED
16000 W / 19000 W / 21000 W
Full chassis loaded with
2 DCS-7516-SUP,
6 DCS7516R-FM
16 DCS-7500R2-36CQ-LC
16 PWR-3KT-AC-RED
13500 W / 15600 W / 17500 W
Full chassis loaded with
2 DCS-7516-SUP,
6 DCS7516R-FM
16 DCS-7500RM-36CQ-LC
20 PWR-3KT-AC-RED
19000 W / 22000 W / 24000 W
Table 1-2 7500N Series power specifications (Continued)
Module Type Part Number
Power Draw (Typical /
{Hot}Maximum)
