Ariston CLAS - Page 64

Training manual CLAS
Pag. 64 di 71
8
3
BOILER’S TEMPERATURE
8
3
0
Temperature set on heating (°C)
(only visualization)
8
3
1
Temperature measured on
heating delivery (°C)
(only visualization)
8
3
2
Heating return measured
temperature (°C)
(only visualization)
8
3
3
Sanitary measured temperature
(°C)
(only visualization)
8
4
SOLAR AND STORAGE (if present)
8
4
0
Storage measured temperature
(°C)
(only visualization)
8
4
1
Solar collector temperature (°C)
(only visualization)
8
4
2
Sanitary inlet temperature (°C)
(only visualization)
8
4
3
Storage probe temperature low
(°C)
(only visualization)
8
4
4
Storage set-point stratification
(°C)
(only visualization)
8
4
5
Solar pump run time
(only visualization)
8
4
6
Collector overheat temperature
time
(only visualization)
8
5
SERVICE
8
5
4
Hardware version main board
(only visualization)
8
5
5
Software version main board
(only visualization)
8
5
6
Software version bus translator
(only visualization)
8
6
STATISTICS
8
6
0
Hours burner on in heating (h)
(only visualization)
8
6
1
Hours burner on in sanitary (h)
(only visualization)
8
6
2
Number of flame faults
(only visualization)
8
6
3
Number of ignition cycles
(only visualization)
8
6
5
Heating request duration
(only visualization)
8
8
ERROR HISTORY
8
8
0
Last 10 errors
In sequence for every error are
visualized the information described in
the following example :
E-0 : error number (E-0 ÷ E-9)
108 : error code
A 15 : day when the error E-0 is
occurred
B 09 : month when the error E-0 is
occurred (September)
C06 : year when the error E-0 is
occurred (2006)
D XX : not used
8
8
1
Reset error list
YES: press button “MENU’/OK”
NO: press button “ESC”
