6.4 BOILER PROTECTION SYSTEMS
There are two types of errors for malfunctions:
- Shutdown (solved by resetting);
- Safety stop (No Reset: the boiler will start working again properly when the cause is removed).
There is a third type of error code that is used to indicate a malfunction that does not stop the boiler which
continues to work properly (Indication).
The Shutdown and the Safety stop are alternatively signalled with the respective error code and the writing
"Err."
6.4.1 Error codes
The error codes are divided in six different functional units, in other words the first figure indicates which
functional unit of the boiler is involved in the error:
1. Primary circuit;
2. Sanitary circuit;
3. Electronic card;
4. Communication with peripherals;
5. Ignition and detection;
6. Air inlet / Smoke outlet.
7. Zones
Display
Description
Reset
PRIMARY CIRCUIT
1 01
Overheat
Reset
1 03
Circulation or presence of water:
Gradient Tman > 7°C/sec for 3 times
Reset
1 04
Circulation or presence of water:
Gradient Tman > 20°C/sec or Gradient Trit > 20°C/sec
Reset
1 05
Circulation or presence of water:
Tman – Trit> 55°C for 3 times
Reset
1 06
Circulation or presence of water:
Trit > Tman + 10°C for 3 times
Reset
1 07
Circulation or presence of water:
Trit > Tman + 30°C
Reset
1 08
Low heating pressure
No Reset
1 10
Heating delivery probe open or short circuit (NTC1)
No Reset
1 12
Heating return probe open or short circuit (NTC2)
No Reset
1 14
Outdoor probe open or short circuit
No Reset
1 16
Floor thermostat opened
No Reset
1 P1
Circulation or presence of water:
Gradient Tman > 7°C/sec
Signalling
1 P2
Circulation or presence of water:
Tman – Trit> 55°C
Signalling
1 P3
Circulation or presence of water:
Trit > Tman + 10°C
Signalling
SANITARY CIRCUIT
2 01
Sanitary probe open or short circuit (NTCs)
No Reset
2 02
Storage low probe open or short circuit (solar)
No Reset
2 03
Storage probe open or short circuit
No Reset
2 04
Solar collector probe open or short circuit
No Reset
2 05
Sanitary inlet probe open or short circuit (solar)
No Reset
2 06
Solar manifold overheat
No Reset
2 07
Solar manifold temperature low (anti-freeze)
No Reset
2 08
Storage overheat
No Reset
2 09
Sanitary probe open or short circuit (NTCs)
Signalling
