The window should now look like this:
Note that the Location of the CLK12M is now set to Location PIN_H6 (as seen in blue colour in the
top view of the FPGA).
5.2.11.3 The other pins need to be assigned as well. Just like previously set all the pins to their
appropriate locations using the table below, by either drag and drop or writing
manually the location.
