13. SPECIFICATIONS
AC Input Specifications
Voltage 100V - 240V AC
Power 85W
Frequency 50-60 Hz
Safeguard fuse characteristics F3.15A, 250v AC
Pedal Connections
Expression (x2) Tip = Pot center tap; Ring = 3.3V; Sleeve = Ground
Sustain Normally open
Sync (TRS)
Gate 0 – 5V
Audio I/O Jack Level
Master Out L/R Mono TS +4dBu
• Operating temp: 15°-35° C (59°-95° F)
• Dimensions: 972x378x110mm
• Weight: 20kg
• Keyboard: 5-octave, velocity-sensitive, channel aftertouch, adjustable curves
• Performance controls
◦ Morphée, a 3-D controller that can modulate parameters along the X,
Y, and Z axes simultaneously
◦ Aftertouch (pressure sensitivity)
◦ Ribbon controller
◦ Pitch and Modulation wheels
◦ Octave buttons can shift keyboard range +/- 2 octaves from center
• Other hardware features
◦ Stereo outputs
◦ MIDI In/Out/Thru connectors
◦ Clock In/Out for integration with modular systems
◦ USB type B connector for use with DAWs and the PolyBrute Editor
◦ Headphone jack with independent level control
Arturia - User Manual PolyBrute - Specifications 101
