ITS101 Installation Manual
option. With the mode Manual you lock up the unit, as you will not be able to connect to
the unit if a reboot occurs. You need to follow the procedure described in Section 3.1 in
order to connect to the unit again.
Warning: do not use the mode Manual as you lock up the unit if a reboot occurs.
• eth0 ip mode has two options in its drop down box; Static or DHCP. Static mode will
assign the IP address, netmask and gateway address listed in the “eth0 ip address” text
box, “eth0 netmask” text box and “eth0 gateway” text box. DHCP mode will request an
IP address from an attached DHCP server.
• eth0 ip address is a text box that allows the user to assign a static IP address for the
LAN connection.
• eth0 netmask is a text box that allows the user to define a netmask for the LAN
connection.
• eth0 gateway is a text box that allows the user to assign a gateway address for the LAN
connection.
After clicking the apply button the new settings will be stored. Only after reboot or after
clicking 're-start' the new settings become active.
3.3. OpenVPN
Communications can be secured by OpenVPN, an open source virtual private network software.
Detailed “how to” guides and software are available at http://openvpn.net.
Note: The date and time settings of the ITS101 unit are important for the OpenVPN
connections, as an incorrect time and date setting can lead to an OpenVPN connection being
rejected. See section 3.4 for configuring the date and time.
The ITS101 runs the OpenVPN software as a client application and as such requires client
certificates and key files to be generated and copied onto the unit in order for the OpenVPN
connection to be established. This can be accomplished by navigating to the “openvpn
settings” page on the web service.
ARVOO Imaging Products B.V. page 14 of 33
