ASCOM D81 Configuration Manual

TD 92674EN
29 April 2015 / Ver. I
Configuration Manual
Ascom d81 DECT Handset
5
2. Getting Started
2. Getting Started
The handset can be configured by inserting it into a DC4 desktop charger or CR3 charging
rack. The charger is connected via USB to the PDM, or via Ethernet to the Device Manager in
the Unite module.
In the case of IP-DECT, the handset can be configured over the air.
This chapter describes how to configure handsets in three different system setups:
•with PDM
• with Device Manager via chargers
• with Device Manager over-the air
2.1 PDM
The Windows Version is run on a PC. The handset is configured via PDM as follows:
1 Connect a DC4 desktop charger or a CR3 charging rack via USB to the computer
r
unning PDM.
2 Start PDM.
3 Place the handset in this charger connected to
PDM. The handset can either be turned
off or turned on when placing it in the charger. A handset that is turned off starts up
automatically and the battery charging symbol is displayed.
PDM
001
For instructions on how to use PDM, see its Installation and Operation Manual.
2.2 Device Manager
The Device Manager is running on an ELISE3 module.
For instructions on how to use the Device Manager, see the Installation and Operation
Manual for the Unite module.
2.2.1 Via Chargers
1 Connect a DC4 desktop charger or a CR3 charging ra
ck via the Ethernet port to the
network.
2 The charger is by default configured to conne
ct to the network using DHCP. If DHCP is
not used in the network, connect each charger via USB to a PDM and configure a
static IP address.
3 Start the Device Manager.
4 Place the handset in a charger that is connected to the Device Manager. Th
e handset
can either be turned off or turned on when placing it in the charger. A handset that is
turned off starts up automatically and the battery charging symbol is displayed
