Ascon Tecnologic - X34 - OPERATING INSTRUCTIONS - PAG. 23
Parameter Description Range Def. Note
49
r.tC
Lengh of Turbo cycle
oF Turbo cycle disabled
0.01 ÷ 9.59 (h.min) ÷ 99.5 (h.min x 10)
oF
]fn Group - Evaporator fans control parameters
Parameter Description Range Def. Note
50
F.tn
Fan time activation with ot output (compressor) OFF
oF FN OFF when ot OFF
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
5.00
51
F.tF
Fan time deactivation with ot output (compressor) OFF
oF If f.tn = any value, FN ON when ot OFF
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
52
F.FL
High temperature fan deactivation - 99.9 ÷ 999 °C/°F 10.0
53
F.LF
Low temperature fan deactivation - 99.9 ÷ 999 °C/°F -99.9
54
F.dF
Differential fan control 0.0 ÷ 30.0°C/°F 1.0
55
F.FE
Fan status during defrost oF - on oF
56
F.Fd
Fan delay after defrost
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
]pr Group - Compressor protection and power on delay parameters
Parameter Description Range Def. Note
57
P.P1
Output ot delay at switch ON
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
58
P.P2
Output ot delay after switch OFF
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
59
P.P3
Output ot delay between 2 switching-ON
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
60
P.od
Delay outputs at power ON
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
]al Group - Alarms parameters
Parameter Description Range Def. Note
61
A.y1
Temperature alarms 1 Type
1 Absolute to Pr1 probe with label (H - L);
2 Relative to Pr1 probe with label (H - L);
3 Absolute to Au probe with label (H - L);
4 Relative to Au probe with label (H - L);
5 Absolute to cd probe with label (H - L);
6 Absolute to Pr1 probe with no label;
7 Relative to Pr1 probe with no label;
8 Absolute to Au probe with no label;
9 Relative to Au probe with no label;
10 Absolute to cd probe with no label;
11 Absolute to EP probe with no label;
12 Absolute to EP probe with label (H - L).
1
62
A.H1
High temperature Alarm 1 threshold
oF Max. alarm disabled
-99.9 ÷ 999 °C/°F
oF
63
A.L1
Low temperature Alarm 1 threshold
oF Min. alarm disabled
-99.9 ÷ 999 °C/°F
oF
64
A.d1
Alarms A.H1 and A.L1 Hysteresis) 0.0 ÷ 30.0°C/°F 1.0
65
A.t1
Alarms A.H1 and A.L1 delay
oF Dealy disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
66
A.P1
Temperature Alarms 1 delay at power on
oF Power ON dealy disabled
0.01 ÷ 9.59 (h.min) ÷ 99.5 (h.min x 10)
2.00
67
A.A1
Alarms H1 e L1 actions
0 No actions
1 Activate alarm outputs
2 Disable (ot e HE) but not activate alarm outputs
3 Disable (ot e HE) and activate alarm outputs
1
68
A.y2
Temperature alarms 2 Type See (61) A.y1 3
69
A.H2
High temperature Alarm 2 threshold
oF Min. alarm disabled
-99.9 ÷ 999 °C/°F
oF
70
A.L2
Low temperature Alarm 2 threshold
oF Min. alarm disabled
-99.9 ÷ 999 °C/°F
oF
71
A.d2
Alarms A.H2 and A.L2 Hysteresis) 0.0 ÷ 30.0°C/°F 1.0
72
A.t2
Alarms A.H2 and A.L2 delay
oF Dealy disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
73
A.P2
Temperature Alarms 2 delay at power on
oF Power ON dealy disabled
0.01 ÷ 9.59 (h.min) ÷ 99.5 (h.min x 10)
2.00
