Ascon Tecnologic - X34 - OPERATING INSTRUCTIONS - PAG. 24
Parameter Description Range Def. Note
74
A.A2
Alarms H2 e L2 actions
0 No actions
1 Activate alarm outputs
2 Disable (ot e HE) but not activate alarm outputs
3 Disable (ot e HE) and activate alarm outputs
1
75
A.dA
Temperature Alarms 1 delay after defrost, and unlock display
delay after defrost
oF Dealy disabled
0.01 ÷ 9.59 (h.min) ÷ 99.5 (h.min x 10)
1.00
76
A.oA
Alarm delay with door open
oF Dealy disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
3.00
77
A.r1 (#)
A.H1 / A.L1 delay to be recorded as an HACCP alarm
oF Alarms never registered as HACCP
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
78
A.r2 (#)
A.H2 / A.L2 delay to be recorded as an HACCP alarm
oF HACCP recording disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
79
A.bo (#)
Black out alarm delay to be recorded as an HACCP alarm oF
80
A.di (#)
DI ext. alarm to be recorded as an HACCP alarm oF
]ou Group - Outputs and buzzer configuration parameters
Parameter Description Range Def. Note
81
o.o1
OUT1 function
oF No function
ot Temperature control (compressor)
dF Defrosting(1)
Fn Fan
Au Auxiliary
At/-t Silenceable alarm
AL/-L Not silenceable Alarm
An/-n Stored alarm
on ON when instrument switch ON
HE Heating (Neutral zone control)
2d Defrosting 2
L1 Light in Eco mode (ON with SP/OFF with SPE)
L2 Internal light (Door close: OFF/Door open: ON)
ot
82
o.o2
OUT2 function dF
83
o.o3
OUT3 function Fn
84
o.o4
OUT4 function Au
85
o.bu
Buzzer function mode
oF Buzzer disableed
1 Active alarms only
2 Key pressed only
3 Active alarms and key pressed
3
86
o.Fo
Function mode auxiliary output
oF No Function
1 Aux. output delayed than ot control output
2 Manual activation by key or digital input
3 Output Suction solenoid (HOT GAS defrost in centralized plants)
oF
87
o.tu
Time relative to auxiliary output
oF Time relative to auxiliary output disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
]ts Group - Keyboard and serial communications parameters
Parameter Description Range Def. Note
88
t.UF
Function mode key
oF No function
1 Auxiliary output command
2 Normal/Eco mode Selection
3 Switch ON/OFF (Stand-by)
4 Turbo cycle command
5 Manual Switch ON/OFF (Stand-by) when set by clock
6 HACCP Alarms Reset
7 HACCP Alarms recording disable/enable
oF
89
t.Fb
Function mode key /Aux
oF
90
t.Lo
Keyboard lock function delay
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
91
t.Ed
Set Point Visibility with fast procedure by key
oF None
1 SP
2 SPE
3 SP and SPE
4 Active SP
5 SP and SPH
6 SP, SPE and SPH
4
92
t.PP
Access Password to parameter functions
oF Password disabled
1 ÷ 999
oF
93
t.HA (#)
HACCP Alarms Parameters level
1 Visible as protected parameters
2 Visible as unprotected parameters
1
94
t.AS
MODBUS Station address (for serial communication) 1 ÷ 255 1
95
t.br
Serial communication baud rate
1 9600
2 19200
3 38400
1
