9
Chapter 3
CPU setup
At start-up, a configuration session is started to setup the system module and
configure the system I/Os. Setup data can be inserted using a VT100 terminal
or a Personal Computer with a Hyper Terminal program or a Telnet client.
3-1 Connect the Setup Terminal
There are 2 ports available on the CPU to enter the configuration session: the
X0 port for the serial RS232 connection or the LAN port for the ethernet
connection. Depending on the setup method used, the user must:
• Set the X0 or the LAN port (consult the “
MP-01 Installation Manual
” [9]
for details);
• Provide the proper connection cable;
• Set the correct communications parameters;
• Run the communications program.
Caution
Appendix A
describes connection and the setup details of the ports connection
and configuration of the communication ports.
Once the setup terminal (VT100 or PC) is correctly connected to the MP-01
basic unit, the user can start the configuration session. In
Appendix C
is
inserted the tree structure of the setup menus.
