1
Chapter 1
Hardware description
The system described in this User Manual is mainly composed of three main
components:
•Ascon
sigmadue microPAC MP-01 with 6 + 2 optional analogue inputs, up
to 4 analogue outputs, 8 digital inputs and 8 digital outputs (ready to work
with OpenPCS EN61131-3 compliant programming system);
•Ascon
sigmadue microPAC I/O modules;
• Infoteam OpenPCS EN61131-3 compliant programming system.
microPAC MP-01, is a powerful processing device, based on an ARM RISC
processor, utilizing different types of memory, some onboard I/O and several
communication ports.
microPAC I/O is a complete family of I/O analogue and digital modules with
special functions that can be connected to the MP-01 module through a
dedicated bus.
Infoteam OpenPCS is a powerful and useful standard programming system for
PLC applications.
It is a clearly structured, easily operated tool for editing, compiling, debugging,
managing and printing PLC applications in all the development phases.
OpenPCS supports EN61131-3 programming under Windows server 2003,
Windows XP SP2 or Windows Vista 32 bit.
The Ascon
sigmadue
microPAC
line is based on the MP-01 module, combining
its functionality with the capabilities of a PLC. “
Modular concept
” means that you
can adapt the system to your requirements quickly and easily. This gives the
sigmadue
automation system an especially economical price/performance ratio.
This User Manual handbook introduces you to the microPAC line and the
Infoteam OpenPCS programming system.
It explains how to install the hardware and software, and how to start up the system.
Information on maintenance, troubleshooting and service are also included.
