Sigmadue - microPAC MP-01 - User manual
24
3-2-17 Local AO Ch Setup Menu
Figure 3.24 - Local AO Setup Menu
Note: Please note that for all 4 optional output channels the setup menu is the same as
described here.
Ch Chosen Analogue Output Channel (Note)
Channel Out Mode
Analogue Output Type
Possible values are:
Value Type
0 -10...+10 V
1 -20...+20 mA
2 0...+10 V
3 0...+20 mA
4 4...+20 mA
Channel Out Value
Using this item the analogue output value can be set:
please note that the range of the value is:
-100.0...+100.0% for dual polarity signals
0...100% for single polarity signals
Exit Return to previous menu
LOCAL AO CH MENU
Ch Number: 3
1. Channel Out Mode (0..4):4 (4... 20mA)
2. Channel Out Value (%): 0.00
3. Exit
Enter Selection:
Ascon S.p.a.
Sigma microPAC Control Unit MP-01
Device configuration
