Sigmadue - microPAC MP-01 - User manual
16
Using the conversion tables that follow, is possible to find the configuration type of
the analogue I/Os.
When the analogue outputs or the optional expansion modules are not installed,
at the correspondig missed channel is possible to read 0xFF (255).

WARNING
At each warm/cold start, the I/O configuration codes are loaded/written in the
marker percentage memory. If the same marker percentage memory areas are
used to store user application data, pay extreme attention to the fact that at each
warm/cold start these memories are written with the I/O configuration codes
causing the destruction of the application data.
3-2-9 Modbus TCP/IP Setup
Figure 3.11 - Modbus TCP/IP Setup Menu
Code
6 High
Level Inputs
(%MB10.0... %MB15.0)
2 optional
High Level Inputs
(%MB20.0... % MB21.0)
2 optional
Universal Inputs
(%MB20.0... % MB21.0)
4 optional
Analogue Outputs
(%MB16.0... % MB19.0)
0 0... 1 V 0... 1 V -15... +15 mV -10... +10 V
1 - -1... +1 V -35... +35 mV -20... +20 mA
2 0... 5 V 0... 5 V -50... +50 mV 0... +10 V
3 - -5... +5 V -100... +100 mV 0... +20 mA
4 1... 5 V 1... +5 V -300... +300 mV 4... +20 mA
5 0... 10 V 0... 10 V -1.25... +1.25 V -
6 - -10... +10 V TC J -
7 0... 20 mA 0... 20 mA TC K -
8 4... 20 mA 4... 20 mA TC L -
9 - -20... +20 mA TC N -
10 -- TC R-
11 -- TC S-
12 -- TC T-
13 -- Pt 100-
14 - - Pt 1000 -
15 - - Potentiometer -
Messages per Cycle
Number of processed messages per cycle.
Valid values from 1... 50
Broken Connection
Timeout
Inactivity Timeout of a TCP/IP connection.
Valid values from 10... 5400 s
MODBUS TCP/IP SETUP
1. Messages per cycle: 10
2. Broken connection timeout(s): 10
3. Secure Address Setup
4. Priority Address Setup
5. Exit
Enter Selection:
