ascon S2 Series User Manual

Chapter 3 - CPU setup
19
3-2-13 Setting the Local I/O ports
Standard Local AI Menu
Select a
Standard
Local AI
Channel
Figure 3.15 - Standard Local AI Selection Menu
Setup the
Selected
Local AI
Channel
Figure 3.16 - Local Analogue Input High Level Setup Menu
Note: Please note that for all 6 high level input channels the setup menu is the same as
described here.
Ch1 Analogue Input Channel 1 Configuration
Ch2 Analogue Input Channel 2 Configuration
Ch3 Analogue Input Channel 3 Configuration
Ch4 Analogue Input Channel 4 Configuration
Ch5 Analogue Input Channel 5 Configuration
Ch6 Analogue Input Channel 6 Configuration
Exit Return to previous menu
LOCAL AI MENU
1. CH1
2. CH2
3. CH3
4. CH4
5. CH5
6. CH6
7. Exit
Enter Selection:
Ascon S.p.a.
Sigma microPAC Control Unit MP-01
Device configuration
CH Number Chosen Analogue Input Channel (Note)
Installed For the high level analogue inputs this item is always “ Yes ”
Channel Input Type
Analogue Input Type
Possible values:
Value Type
0 0...+1 V
1 0... +5 V
2 1...+5 V
3 0...+10 V
4 0...+20 mA
5 4...+20 mA
Read Value Input value read
Refresh Refresh command to update the “ Read Value ” item
Exit Return to previous menu
LOCAL AI HL CH MENU
CH NUMBER: 1
1. Installed: Y
2. Channel Input Type (0..5): 3 (0 10 Volt)
3. Read Value: 0.00 V
4. Refresh
5. Exit
Enter Selection:
Ascon S.p.a.
Sigma microPAC Control Unit MP-01
Device configuration
