3-2-3 Serial Setup Menu
Figure 3.4 - Serial Setup Menu
3-2-4 CPU Setup Menu
Figure 3.5 - CPU Setup Menu
Baudrate
Serial Setup Connection Baudrate
Possible Values
Value Baudrate
02400
14800
29600
3 19200
4 38400
5 57600
6 115200
Parity
Serial Setup Connection Parity
Possible Values
Value Parity
0None
1Even
2Odd
Stop bit
Serial Setup Connection Stop bit: valid values are 1 or 2
Exit
Return to previous menu
SERIAL SETUP MENU
1. Baudrate: 2, (9600 bps)
2. Parity: 0 (NO PARITY)
3. Stop Bit: 1
4. Exit
Enter Selection:
Ascon S.p.a.
Sigma microPAC Control Unit MP-01
Device configuration
Startup Timeout Setup Timeout Setup Parameters
Persistency Setup Persistency Parameters
Clock Setup Real Time Clock Settings
Retain Config Retentive Registers Configuration
Exit Return to previous menu
CPU SETUP MENU
1. Startup Setup
2. Persistency Setup
3. Clock Setup
4. Retain Config
5. Exit
Enter Selection:
Ascon S.p.a.
Sigma microPAC Control Unit MP-01
Device configuration
