Sigmadue - microPAC MP-01 - User manual
18
3-2-12 I/O Setup Menu
Figure 3.14 - I/O Setup Menu
Note: The presence/absence in the system of either 2 Optional High Level Analogue
Inputs or 2 Optional Universal Inputs is determined by the order code.
Local High Level AI High Level Analogue Inputs Configuration
Optional High Level
AI
Optional High Level Analogue Inputs Configuration.
If this option is present the CPU inserts automatically the
tag “
Ye s ” . Otherwise the tag used is “ No ” [note].
Optional Universal
AI
Optional Universal Analogue Inputs Configuration.
If this option is present the CPU inserts automatically the
tag “
Ye s ” . Otherwise the tag used is “ No ” [note].
Local AO
CH1 & CH2
Analogue Outputs 1 and 2 Configuration.
If this option is present the CPU inserts automatically the
tag “
Ye s ” . Otherwise the tag used is “ No” .
Local AO
CH3 & CH4
Analogue Outputs 3 and 4 Configuration.
If this option is present the CPU inserts automatically the
tag “
Ye s ” . Otherwise the tag used is “ No ”.
Expansion 1
First Expansion Unit Configuration.
If this option is present the CPU inserts automatically the
tag “
Ye s ” . Otherwise the tag used is “ No ”.
Expansion 2
Second Expansion Unit Configuration.
If this option is present the CPU inserts automatically the
tag “
Ye s ” . Otherwise the tag used is “ No ”.
Temperature Onboard Temperature measurement
Exit Return to previous menu
I/O SETUP MENU
1. Local High Level AI
2. Optional High Level AI: Yes
3. Optional Universal AI: No
4. Local AO CH1 & CH2: Yes
5. Local AO CH3 & CH4: Yes
6. Expansion 1: No
7. Expansion 2: No
8. Temperature
9. Exit
Enter Selection:
Ascon S.p.a.
Sigma microPAC Control Unit MP-01
Device configuration
