5.1 MECHANICAL INSTALLATION
The converters are designed for vertical, bulkhead-mounted installations and as such are provided
with six mounting ears, three per side. The provided mounting holes are ½” (12.7mm) in diameter;
stainless steel hardware in the size range of 7/16” to ½” (11 to 12mm) is required for mounting.
The mounting surface should be flat and dimensionally stable to within 1/16” (1.5mm) to prevent
torsional stresses being applied to the structure of the converter. Spacers (shim stock) may be added
between the mounting surface and the converter mounting ears to adjust the mounting plane.
Resilient mounts must not be used directly between the converter and the mounting surface. If the
converter is to be mounted in a high vibration/shock environment, then the factory must be consulted
concerning the application. Drawings for approved shock mounting panels will be supplied.
The converter may be mounted horizontally with the correct preparations to the mounting surface.
The factory must be contacted concerning the application prior to order/delivery of the system to
allow the required internal modifications to be included, and for concurrence on the application and
installation.
The following recommended clearances must be considered during installation:
TABLE 1
FOR PROPER
Operation Service
Front 6” (Airflow) 24” min
Bottom 6” (Airflow) N/A
Sides 6” (Airflow) 6”
Top 0” 6”
