AC08 and AC12 Operations Manual....
31
WATT-HOUR METER Run-Time:day:HH:MM:SS
INPUT kW-Hours:XXXXXXX.XX Max: XX%
ONLINE Real-Power:XX.XXkW Level: XX%
Exit Clear
7.3 WATT-HOUR METER AND MAXIMUM POWER DISPLAY
Press the SHORE POWER + F1 buttons to access the Automatic WATT-HOUR METER and
maximum power display.
Press the Clear (F2) button to clear all data and the Exit (SYSTEM STATUS) button to exit.
Application: this reference kW-hour meter can be used to check the billing received in a marina for
consumption of electric energy. Immediately after connecting shore power and turning the
converter's red disconnect switch, clear the data in this screen. When ready to leave, take down the
kW-hours and run time before disconnecting the shore power.
Additionally, this screen can be used to diagnose converter shutdowns. Since the Max. (greatest
kW) and Level (greatest percentage of System Level) data are updated with slow-response metering
(approximately 1 second), only average use data are represented. Instantaneous motor-start surges
and such will not be represented by the data. If the Level exceeds 110%, and a shutdown of the
Shore Power has occurred, it is very likely the average loading is exceeding the converter's capacity.
The Max (kW) is provided since Level is affected by Shore Cord Setup settings.
