AC08 and AC12 Operations Manual....
10
4 SPECIFICATIONS
4.1 ELECTRICAL SPECIFICATIONS
Parameter
AC08 AC12
4.1.1 Input Service
Input Power Form Single Phase Single Phase
Input Voltage Range 170-520 V
AC
170-520 V
AC
Input Frequency Range 40-70 Hertz 40-70 Hertz
Input Current, Max., Std Range 40 A
RMS
55 A
RMS
Input Current, Soft Start, Max. 20 A
RMS
20 A
RMS
Input Current Distortion <10% @ rated load <10% @ rated load
Input Power Factor >0.95 @ rated load >0.95 @ rated
4.1.2 Output Service
Output Power Rating 8kVA @ 0.85 p.f. 12kVA @ 0.85 p.f.
Output Power Form Single Phase 220, 230, or 240 V
RMS
and
Split Phase 110/220, 115/230, or 120/240 V
RMS
Output Frequency 50 or 60 Hertz 50 or 60 Hertz
Output Frequency Accuracy 0.01% 0.01%
Output Voltage Distortion < 1% THD < 1% THD
Output Voltage Line Regulation 0.50% 0.50%
Output Voltage Load Regulation 1.0% 1.0%
Output Voltage Response Time 0.20 msec. 0.20 msec.
Output Current, Continuous 35 A
RMS
@ 0.85 p.f. 50 A
RMS
@ 0.85 p.f.
Output Current, Peak 420% of continuous rating 420% of continuous rating
Output Current, Surge 300% of continuous rating 300% of continuous rating
Conversion Efficiency 87% @ rated load 88% @ rated load
