AC08 and AC12 Operations Manual....
20
5.2 ELECTRICAL INSTALLATION, cont.
5.2.3 Grounding
The converter chassis ground MUST be connected to the ship’s hull or common ground point via the
compression fitting terminal adjacent to the output power connections. Failure to do so may create
conditions that may in turn cause injury or death to operators; failure to do so will also result in the
voiding of the equipment warranty. In the case of paralleled converter systems, and where such
ground connections are not local and directly adjacent to the paralleled converters, the chassis
ground connections must be interconnected between the paralleled converters as well as connected
to the remote ship’s common ground point.
THE CONVERTER ISOLATES THE OUTPUT POWER FROM THE INPUT
POWER AND EQUIPMENT (SAFETY) GROUNDS SIMILAR TO AN ISOLATION
TRANSFORMER. THE INSTALLER MUST RE-ESTABLISH THE GROUND
REFERENCE FOR THE EQUIPMENT AT TIME OF INSTALLATION. THE
NEUTRAL AND EQUIPMENT (SAFETY) GROUNDS MUST TO BE CONNECTED
PER THE APPROPRIATE CLASS STANDARD.
