AGC CONTROL SCREEN
Automatic Gain Control is: ENABLED
Va_out: 120.00 Vb_out: 120.00 Active
Line-to-Neutral Exit Enable Disable
7 SOFTWARE FEATURES
7.1 GENERAL
ASEA Power Systems' shore power converters provide a variety of software-based resources. Each
major function is described in detail in the following pages.
BOLD upper-case text indicates when a display button is being referenced. Where two buttons are
given as BUTTON + BUTTON, the buttons must be pressed simultaneously.
7.2 AGC CONTROL
Press the CONVERTER POWER + F2 buttons to access the Automatic Gain Control (AGC)
CONTROL display.
This function enables or disables AGC. Press the Enable (F1) button to enable the feature, the
Disable (F2) button to disable the feature, and the Exit (SYSTEM STATUS) button to save the
settings and exit.
Default Range
Automatic Gain Control Enabled Enabled, Disabled
Application: this function will compensate for changes in output voltage not already corrected by
hardware and software calibration such as load-dependent output voltage variances. This function
should be disabled before calibrating the hardware oscillator pots on the Modulator PCB (usually
only done when initially setting the output voltage configuration at the factory).
