AC08 and AC12 Operations Manual....
37
8.3 STATUS WORD
To aid in system diagnostics, a STATUS WORD has been provided in the SUMMARY DISPLAY.
This STATUS WORD contains information about internal logic levels and changes dynamically in
accordance with the converter’s operational state.
The STATUS WORD is comprised of 16 digits—each indicating a separate internal logic term (see
Figure 9 and the subsequent text on the following page for a description of the individual bits).
Press the SYSTEM STATUS (7) and F2 (9) buttons simultaneously to access the STATUS display.
In the STATUS display, the STAUS WORD is given in binary (SW1) and HEX format (STATUS1).
If reporting problems to an authorized service center or the factory, please use the HEX format
(example... STATUS 1: DF85) to reduce the chance of transcription error.
If a problem has been encountered by the system, carefully record the Status Word before removing
power to the system (Diagnostic data may be deleted or reset with power cycling). When calling the
factory for assistance, please have the Status Word handy along with the system model, serial
number, and software version number.
Pressing the SYSTEM STATUS (7) and F1 (8) buttons simultaneously opens a system data screen
containing the converter software version as well as the accumulated run-hours.
SUMMARY DISPLAY AC12 LOAD:XXX.X %
INPUT#1:OFFLINE STATUS: OK
SYS:XXXXXXXXXXXXXXXX CONVERTER: OFFLINE
AUTO-RESTART: OFF XX:XX:XX
STATUS DISPLAY CONFIG: XXXX
BIT:FDECBA9876543210 CONTROL:
SW1:XXXXXXXXXXXXXXXX STATUS1: XXXX
