AC08 and AC12 Operations Manual....
11
4.1 ELECTRICAL SPECIFICATIONS, cont.
4.1.3 Control, Metering, and Status
Shore Power Control Input Service Disconnect Switch, 2 pos.
Membrane Switch, Input ON/OFF Control
Converter Power Control Membrane Switch, Output ON/OFF Control
Shore Power Metering Voltage, Current, Frequency, kVA, kW, %Load
Converter Power Metering Voltage, Current, Frequency, kVA, kW, %Load
System Status Operational status, Diagnostics, Software Calibration
4.2 PHYSICAL SPECIFICATIONS
Parameter AC08 AC12
4.2.1 Mechanical
Height 20”/50.8cm 20”/50.8cm
Width, Enclosure 23”/58.4cm 23”/58.4cm
Width, Mtg. Brackets 25”/63.7cm 25”/63.7cm
Depth 10”/25.4cm 10”/25.4cm
Weight 230lbs/104kg 230lbs/104kg
4.2.2 Environmental
Ambient Temperature Range 0-45C non-condensing 0-45C non-condensing
Air Exchange Rate 300CFM 300CFM
