ASG-SD2500 Operation
First-time users should take some time to become familiar with the ASG-SD2500 prior to use. With the power to the
controller off, cycle the lever and push-to-start spindle to become accustomed to the feel and resistance. Repeat this
step with the controller power on, to feel the operation of the tool.
Motor Specifications
Motor Voltage: 32 VDC
Motor Power: 50 Watt
Forward/Reverse
Depress and release the forward/reverse button on the tool to switch between forward (RH rotation) and reverse (LH
rotation). A straightforward way to know which mode the tool is in is that if the colored LED lights are flashing on/off,
the tool is in reverse.
Changing Bits
Bits can be changed easily through the use of the Quick-Change Chuck that comes standard with the inline versions of
the ASG-SD2500 Screwdriver. Inline drivers (PL, PS, & FX models) are intended to use ¼” hex power bits. Right angle
models utilize either ¼” square sockets for the RP model, or ¼” insert bits for the RQ models. Power drive bits are not
recommended for the RQ models.
To insert a bit: Align the bit’s hex end into the spindle opening. Grasp the black collar on the quick change chuck and
push it away from the tool towards the bit. Apply pressure to the bit until it clicks into place. Release the black collar
and gently pull on the bit to ensure it is seated and locked into place.
