10. Data Button: Displays a table that contains rundown characteristics for the last 100 fastening cycles.
Additional data is available in the internal memory and can also be downloaded to a USB
flash drive from this screen.
11. Repeat Button: Depressing this button keeps the controller on the current bolt in a batch. The bolt
sequence will not advance to the next bolt until the button is released.
12. Reset Button: Depressing this button resets the fastening bolt count in the event of a failure, retry
lockout, or user request. The reset button also resets any currently active outputs. This
button may be disabled when the controller is locked with a password.
13. Outputs: Displays (1) radio button for each of the (8) available outputs. The appropriate radio
button will illuminate blue when the corresponding output relay is closed.
