ADR111A /
ADR211A
Insulation Tests:
I.
Dielectric Test IEC60255-27 : At 2kV 50Hz
a) Between all terminals connected together and
case earth for 1 minute
b) Between independent circuits with case earth
for 1 minute.
II.
Impulse Voltage
Test
IEC60255-27 Test Voltage
Energy
No. of impulses
Polarity
EUT Condition
5kv, 1.2/50 µSec
0.5 J
3 on each
+ve and –ve
Non Energized
III.
Insulation
Resistance
IEC60255-27 : ≥ 100MΩ @ 500V DC
Environmental tests:
I.
Cold test : IEC-60068-2-1
II.
Dry heat test : IEC-60068-2-2
III.
Damp heat test, steady state : IEC-60068-2-78
IV.
Change of Temperature : IEC-60068-2-14
V.
Damp heat test, cyclic : IEC-60068-2-30
VI.
Enclosure Protection Test
IP52 (with optional IP cover)
IP31 (without optional IP cover)
: IEC 60529
CE compliance
I.
Immunity : IEC-60255-26
II.
Emissive Test : IEC- 60255-26
III.
Low voltage directive : EN-50178
Mechanical tests
I.
Vibration
Endurance Test
: IEC 60255-21-1 class 2
: Frequency Range = 10Hz – 250Hz, acceleration. = 2gn
: Sweep rate 1 octave/min; 20 cycle in 3 orthogonal axis.
II.
Vibration
Response Test
: IEC 60255-21-1 class 2
: Frequency Range = 10Hz – 150Hz , acceleration. = 1gn
: Sweep rate 1 octave/min; Displacement =0.075mm, in 3
orthogonal axis.
