Ashida ADR111A - Page 26

Doc ID : ADR
1
11
A_IM_01
Ref ID : ADR111A/IM/I&S
Rev No. : 04
Page No. : 26 of 127
ADR111A /
ADR211A
III.
Bump Test : IEC 60255-21-2 Class-1
: 1000 bumps / direction of 10gn peak acceleration and 16ms pulse
duration in each of the two opposite direction per axis as per No.
of axes. 3.
IV.
Shock Withstand
Test
: IEC 60255-21-2 Class-2 30g, 11ms
: 3 shocks of 15gn peak acceleration and 11ms pulse in each of
two opposite direction. No. of axis : 3
V.
Shock Response
Test
: IEC 60255-21-2 Class-2
: 5 shocks of 10gn peak acceleration and 11ms pulse in each of
two opposite direction. No. of axis : 3
VI.
Seismic Test : IEC 60255-21-3 Class-2
: Sweep 1/Axis (@a sweep rate of 1 octave/minute) vibration in the
frequency range (5-35 Hz) at displacement X-axis: 7.5mm, Y-
axis: 3.5mm amplitude of 3.5mm with acceleration of X-axis: 2gn,
Y-axis: 1gn.
