3 PC SOFTWARE INFORMATION
3.1 Overview
ASHIDA Provides following Software solution to support the ADR211A single pole Protection
Relay and the other ASHIDA products.
Sr. No. Application Software Description
1 ASHIDA Relay-Talk Customizes ADR211A Settings and to view
events, history faults, online measurements
2 DR Analysis Disturbance Record viewer
This section describes how to get started with the ADR211A and Relay Talk software. It
particularly explains about the software setup and working procedure.
3.1.1 Relay Talk Software Features
Connections ADR211A connected to the PC through Front port as well as Rear
port.
Settings Editor Provides online utility to interface with ASHIDA Relay series.
*I/O Mask Allows user to program the inputs, outputs and LEDs
Events Provides event analysis tool.
History Faults Provides History fault analysis tool
*Disturbance Record Provides oscillographic analysis tool.
Time Synchronization Local clock time synchronized data is available.
Measurements Provides online power system parameter measurements.
Status Provides status of the inputs, outputs and protection functions
tool.
Control Provides the control function tool (output, input, LED)
NOTE: The above features are generally provided with all the ASHIDA Relays but the * marked
features are not applicable to this product
